Power Source
|
DC12V power input interface power consumption 120mA
|
|
Image Sensor
|
1/3" 4M pixels low light CMOS
|
|
Video Processing
|
H.265+/H.265/H.264 video encoding, support code stream 0.1M~2Mbps adjustable;
|
|
Lamp Board Interface
|
Integrated dual street light board driver module
|
|
Image Output
|
Main stream：2304×1296，1920×1080，1280×720；
|
|
Subcode stream：640×360；
|
|
Audio Interface
|
Support 1 channel MIC input, 1 channel amplifier output (8Ω2W) and 1 channel active output;
|
|
Audio Processing
|
G.711 coding standard, support two-way voice intercom, support audio and video synchronization;
|
|
Network Interface
|
1 RJ45 Ethernet interface, 10/100M adaptive.
|
|
TF Interface
|
1 TF card storage interface, maximum support 512G
|
|
WiFi
|
2.4GHz/5GHz, WiFi standard IEEE 802.11 a/b/g/n;
|
|
Reset Key Interface
|
Support hardware reset, reset unbind the device;
|
|
Reliability
|
Power supply, network comprehensive lightning protection, in line with national standards GB/T17626.5, international standards IEC61000-4-5;
|
|
Business Function
|
Support OSD, real-time audio and video transmission, accurate human detection, dual light source alarm, sound alarm;
|
|
Network Protocol
|
Support TCP/TP,IPv4,DHCP,RTSP,P2P；
|
|
Mobile Monitoring
|
Support mobile monitoring(iOS, Android) Support AC18Pro, VS365;
|
|
Working environment
|
14℉～131℉
|
|
Product Size
|
7.1*5.6*10.7（inch)
|
|
Package Size
|
6.3*5.8*12.9（inch)
|
|
Product weight (with packaging)
|
830±100（g）
|
