Power Source
|
DC12V power input interface power consumption 100mA
|
|
Image Sensor
|
3M pixels, 1/3" CMOS
|
|
Video Processing
|
H.265+/H.265/H.264 video encoding, support code stream 0.1M~3Mbps adjustable; support frame rate 1~25 frames/sec adjustable;
|
|
Image Output
|
Main stream：25FPS（2560×1440，2304×1296，1920×1080，1280×720)；
|
|
Subcode stream：D1,VGA,640×360；
|
|
Audio Interface
|
Audio linear 1 input and 1 output;
|
|
Audio Processing
|
G.711 coding standard, support two-way voice intercom, support audio and video synchronization;
|
|
IRCUT Interface
|
Integrated IRCUT switching circuitry, auto/external control/manual/timing to control IRCUT day/night mode
|
|
Network Interface
|
1 RJ45 Ethernet interface, 10/100M adaptive.
|
|
Lamp Board Interface
|
PWM infrared, PWM warm light;
|
|
Reliability
|
Power supply, network comprehensive lightning protection, in line with national standards GB/T17626.5, international standards IEC61000-4-5;
|
|
Business Function
|
Support OSD, real-time audio and video transmission, accurate human detection, dual light source alarm, sound alarm;
|
|
Network Protocol
|
Support HTTP/RTSP/DHCP/NTP/ONVIF and other network protocols
|
|
Working environment
|
-40℉～+149℉
|
|
Size
|
3.3*1.7*1.7（inch)
|
