Parameter
|
|
CPU
|
QCA9563+QCA9886+QCA8334
|
|
Flash
|
SPI NOR 16MB
|
|
DDR
|
DDR2-128MB
|
|
5G operating band
|
5.150GHz∽5.850GHz
|
|
2.4G WIFI transmission protocol
|
802.11 a / n /ac wave2
|
|
Maximum speed
|
900Mbps
|
|
antenna
|
Device leads to 2 SMA connectors (external pattern with internal pins) for external antennas
|
|
5G wireless power
|
802.11a
|
54M
|
21±2dBm
|
6M
|
24±2dBm
|
|
802.11n HT20
|
MCS7
|
20±2dBm
|
MCS0
|
23±2dBm
|
|
802.11n HT40
|
MCS7
|
19±2dBm
|
MCS0
|
22±2dBm
|
|
802.11AC
|
MCS9
|
18±2dBm
|
MCS0
|
21±2dBm
|
|
5G receiving sensitivity
|
802.11a
|
54M
|
-72dBm
|
6M
|
-92dBm
|
|
802.11n HT20
|
MCS7
|
-70dBm
|
MCS0
|
-89dBm
|
|
802.11n HT40
|
MCS7
|
-68dBm
|
MCS0
|
-87dBm
|
|
802.11AC
|
MCS9
|
-58dBm
|
MCS0
|
-85dBm
|
|
5G EVM
|
802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；802.11AC_MCS9:≤-32dB
|
|
Frequency offset (ppm)
|
±20ppm
|
|
Interface (WAN)
|
One 10/100/1000M adaptive WAN port, supporting 24-48V POE power supply
|
|
Interface (LAN)
|
One 10/100/1000M adaptive LAN port.
|
|
Power supply
|
PoE 24V∽48V，DC 12∽48V
|
|
MAX power consumption
|
< 15W
|
|
RST key
|
Press the button for 2-5 seconds to automatically pair, and press and hold for 10 seconds to restore the factory default configuration
|
|
Slide switch
|
Set master/slave with one click
|
|
Status light
|
SYS light, WAN port light, LAN port light, 5G WIFI light, four signal light
|
|
Product size
|
7.8*3.4*1.6inch
|
|
Weight
|
0.4kg
|
|
Operating environment
|
Normal operating temperature :-22℉∽131℉
|
|
Limit operating temperature :-40℉∽158℉
|
|
Storage temperature: -40℉∽158℉
|
|
Humidity: 5% to 95% (non-condensing)
|
|
Protection grade
|
IP65
|
|
ESD
|
Air discharge +/-8K, contact discharge +/-4K
|
|
surge
|
Common mode 4K, difference mode 2K
|
